Sqoop

sqoop概述

Sqoop(发音：skup)是一款开源的工具，主要用于在Hadoop(Hive)与传统的数据库(mysql、postgresql…)间进行数据的传递，可以将一个关系型数据库（例如： MySQL ,Oracle ,Postgres等）中的数据导进到Hadoop的HDFS中，也可以将HDFS的数据导进到关系型数据库中。

导入数据：MySQL，Oracle导入数据到Hadoop的HDFS、HIVE、HBASE等数据存储系统；

导出数据：从Hadoop的文件系统中导出数据到关系数据库

mysql <—-à hdfs

注意：1.99.7与1.4.6不兼容，且没有特征不完整，它并不打算用于生产部署。

Sqoop原理

将导入或导出命令翻译成mapreduce程序来实现。

在翻译出的mapreduce中主要是对inputformat和outputformat进行定制。

Sqoop安装

安装Sqoop的前提是已经具备Java和Hadoop的环境。

下载并解压

官网

上传至服务器并解压，解压命令如下：

1	[root@hadoop01 ~]# tar -zxvf sqoop-1.4.6.bin__hadoop-2.0.4.tar.gz -C /usr/local/

配置环境变量

vi /etc/profile

export SQOOP_HOME=/usr/local/sqoop-1.4.6.bin__hadoop-2.0.4-alpha
export PATH=$PATH:$JAVA_HOME/bin:$HADOOP_HOME/bin:$HADOOP_HOME/sbin:$ZOOKEEPER_HOME/bin:$ZOOKEEPER_HOME/sbin:$HIVE_HOME/bin:$ZEPPELIN_HOME/bin:$HBASE_HOME/bin:$SQOOP_HOME/bin

source /etc/profile

修改配置

Sqoop的配置文件与大多数大数据框架类似，在sqoop根目录下的conf目录中。

重命名配置文件

将临时文件的template去掉。（也可对配置文件进行拷贝，保留原始template文件做恢复备份）
1
[root@hadoop01 conf]# mv sqoop-env-template.sh sqoop-env.sh

修改配置文件

sqoop-env.sh

#Set path to where bin/hadoop is available
export HADOOP_COMMON_HOME=/usr/local/hadoop-2.7.3

#Set path to where hadoop-*-core.jar is available
export HADOOP_MAPRED_HOME=/usr/local/hadoop-2.7.3

#set the path to where bin/hbase is available
export HBASE_HOME=/usr/local/hbase-1.3.2

#Set the path to where bin/hive is available
export HIVE_HOME=/usr/local/apache-hive-1.2.2-bin

#Set the path for where zookeper config dir is
export ZOOKEEPER_HOME= /usr/local/zookeeper-3.4.6
export ZOOCFGDIR=/usr/local/zookeeper-3.4.6/conf

拷贝JDBC驱动

拷贝jdbc驱动到sqoop的lib目录下

1
2
3

[root@hadoop01 lib]# pwd
/usr/local/sqoop-1.4.6.bin__hadoop-2.0.4-alpha/lib
[root@hadoop01 lib]# cp /root/zeppelin-lib/mysql-connector-java-5.1.37.jar $PWD

验证Sqoop

[root@hadoop01 ~]# sqoop help
/usr/local/sqoop-1.4.6.bin__hadoop-2.0.4-alpha/conf/sqoop-env.sh: line 35: export: `/usr/local/zookeeper-3.4.6': not a valid identifier
Warning: /usr/local/sqoop-1.4.6.bin__hadoop-2.0.4-alpha/../hcatalog does not exist! HCatalog jobs will fail.
Please set $HCAT_HOME to the root of your HCatalog installation.
Warning: /usr/local/sqoop-1.4.6.bin__hadoop-2.0.4-alpha/../accumulo does not exist! Accumulo imports will fail.
Please set $ACCUMULO_HOME to the root of your Accumulo installation.
Warning: /usr/local/sqoop-1.4.6.bin__hadoop-2.0.4-alpha/../zookeeper does not exist! Accumulo imports will fail.
Please set $ZOOKEEPER_HOME to the root of your Zookeeper installation.
20/07/24 19:34:41 INFO sqoop.Sqoop: Running Sqoop version: 1.4.6
usage: sqoop COMMAND [ARGS]

Available commands:
  codegen            Generate code to interact with database records
  create-hive-table  Import a table definition into Hive
  eval               Evaluate a SQL statement and display the results
  export             Export an HDFS directory to a database table
  help               List available commands
  import             Import a table from a database to HDFS
  import-all-tables  Import tables from a database to HDFS
  import-mainframe   Import datasets from a mainframe server to HDFS
  job                Work with saved jobs
  list-databases     List available databases on a server
  list-tables        List available tables in a database
  merge              Merge results of incremental imports
  metastore          Run a standalone Sqoop metastore
  version            Display version information

See 'sqoop help COMMAND' for information on a specific command.

测试Sqoop是否能够成功连接数据库

sqoop-list-databases --connect jdbc:mysql://192.168.88.110:3306/  --username root --password 123456
#结果如下
/usr/local/sqoop-1.4.6.bin__hadoop-2.0.4-alpha/conf/sqoop-env.sh: line 35: export: `/usr/local/zookeeper-3.4.6': not a valid identifier
Warning: /usr/local/sqoop-1.4.6.bin__hadoop-2.0.4-alpha/../hcatalog does not exist! HCatalog jobs will fail.
Please set $HCAT_HOME to the root of your HCatalog installation.
Warning: /usr/local/sqoop-1.4.6.bin__hadoop-2.0.4-alpha/../accumulo does not exist! Accumulo imports will fail.
Please set $ACCUMULO_HOME to the root of your Accumulo installation.
Warning: /usr/local/sqoop-1.4.6.bin__hadoop-2.0.4-alpha/../zookeeper does not exist! Accumulo imports will fail.
Please set $ZOOKEEPER_HOME to the root of your Zookeeper installation.
20/07/24 19:36:24 INFO sqoop.Sqoop: Running Sqoop version: 1.4.6
20/07/24 19:36:24 WARN tool.BaseSqoopTool: Setting your password on the command-line is insecure. Consider using -P instead.
20/07/24 19:36:24 INFO manager.MySQLManager: Preparing to use a MySQL streaming resultset.
information_schema
hive
mysql
performance_schema
sys
zeppelintest

将mysql中的所有库名展示出来了。

Sqoop的简单使用案例

导入数据

在Sqoop中，“导入”概念指：从非大数据集群（RDBMS）向大数据集群（HDFS，HIVE，HBASE）中传输数据，叫做：导入，即使用import关键字。

RDBMS（关系型数据库）到HDFS

确定Mysql服务开启正常
在Mysql中新建一张表并插入一些数据

mysql中数据如下：

导入数据

全部导入

sqoop import \
--connect jdbc:mysql://192.168.88.110:3306/test \
--username root \
--password 123456 \
--table student \
--target-dir /sqoop/mysql/student \
--delete-target-dir \
--m 1 \
--fields-terminated-by "\t"

运行过程打印日志信息如下：

/usr/local/sqoop-1.4.6.bin__hadoop-2.0.4-alpha/conf/sqoop-env.sh: line 35: export: `/usr/local/zookeeper-3.4.6': not a valid identifier
Warning: /usr/local/sqoop-1.4.6.bin__hadoop-2.0.4-alpha/../hcatalog does not exist! HCatalog jobs will fail.
Please set $HCAT_HOME to the root of your HCatalog installation.
Warning: /usr/local/sqoop-1.4.6.bin__hadoop-2.0.4-alpha/../accumulo does not exist! Accumulo imports will fail.
Please set $ACCUMULO_HOME to the root of your Accumulo installation.
Warning: /usr/local/sqoop-1.4.6.bin__hadoop-2.0.4-alpha/../zookeeper does not exist! Accumulo imports will fail.
Please set $ZOOKEEPER_HOME to the root of your Zookeeper installation.
20/07/24 19:45:10 INFO sqoop.Sqoop: Running Sqoop version: 1.4.6
20/07/24 19:45:10 WARN tool.BaseSqoopTool: Setting your password on the command-line is insecure. Consider using -P instead.
20/07/24 19:45:10 INFO manager.MySQLManager: Preparing to use a MySQL streaming resultset.
20/07/24 19:45:10 INFO tool.CodeGenTool: Beginning code generation
20/07/24 19:45:11 INFO manager.SqlManager: Executing SQL statement: SELECT t.* FROM `student` AS t LIMIT 1
20/07/24 19:45:11 INFO manager.SqlManager: Executing SQL statement: SELECT t.* FROM `student` AS t LIMIT 1
20/07/24 19:45:11 INFO orm.CompilationManager: HADOOP_MAPRED_HOME is /usr/local/hadoop-2.7.3
注: /tmp/sqoop-root/compile/29825426f428c228e971e547c536c287/student.java使用或覆盖了已过时的 API。
注: 有关详细信息, 请使用 -Xlint:deprecation 重新编译。
20/07/24 19:45:16 INFO orm.CompilationManager: Writing jar file: /tmp/sqoop-root/compile/29825426f428c228e971e547c536c287/student.jar
SLF4J: Class path contains multiple SLF4J bindings.
SLF4J: Found binding in [jar:file:/usr/local/hadoop-2.7.3/share/hadoop/common/lib/slf4j-log4j12-1.7.10.jar!/org/slf4j/impl/StaticLoggerBinder.class]
SLF4J: Found binding in [jar:file:/usr/local/hbase-1.3.2/lib/slf4j-log4j12-1.7.5.jar!/org/slf4j/impl/StaticLoggerBinder.class]
SLF4J: See http://www.slf4j.org/codes.html#multiple_bindings for an explanation.
SLF4J: Actual binding is of type [org.slf4j.impl.Log4jLoggerFactory]
20/07/24 19:45:17 INFO tool.ImportTool: Destination directory /sqoop/mysql/student is not present, hence not deleting.
20/07/24 19:45:17 WARN manager.MySQLManager: It looks like you are importing from mysql.
20/07/24 19:45:17 WARN manager.MySQLManager: This transfer can be faster! Use the --direct
20/07/24 19:45:17 WARN manager.MySQLManager: option to exercise a MySQL-specific fast path.
20/07/24 19:45:17 INFO manager.MySQLManager: Setting zero DATETIME behavior to convertToNull (mysql)
20/07/24 19:45:17 INFO mapreduce.ImportJobBase: Beginning import of student
20/07/24 19:45:17 INFO Configuration.deprecation: mapred.jar is deprecated. Instead, use mapreduce.job.jar
20/07/24 19:45:17 INFO Configuration.deprecation: mapred.map.tasks is deprecated. Instead, use mapreduce.job.maps
20/07/24 19:45:17 INFO client.RMProxy: Connecting to ResourceManager at hadoop01/192.168.88.110:8032
20/07/24 19:45:19 WARN hdfs.DFSClient: Caught exception
java.lang.InterruptedException
        at java.lang.Object.wait(Native Method)
        at java.lang.Thread.join(Thread.java:1252)
        at java.lang.Thread.join(Thread.java:1326)
        at org.apache.hadoop.hdfs.DFSOutputStream$DataStreamer.closeResponder(DFSOutputStream.java:609)
        at org.apache.hadoop.hdfs.DFSOutputStream$DataStreamer.endBlock(DFSOutputStream.java:370)
        at org.apache.hadoop.hdfs.DFSOutputStream$DataStreamer.run(DFSOutputStream.java:546)
20/07/24 19:45:19 WARN hdfs.DFSClient: Caught exception
java.lang.InterruptedException
        at java.lang.Object.wait(Native Method)
        at java.lang.Thread.join(Thread.java:1252)
        at java.lang.Thread.join(Thread.java:1326)
        at org.apache.hadoop.hdfs.DFSOutputStream$DataStreamer.closeResponder(DFSOutputStream.java:609)
        at org.apache.hadoop.hdfs.DFSOutputStream$DataStreamer.endBlock(DFSOutputStream.java:370)
        at org.apache.hadoop.hdfs.DFSOutputStream$DataStreamer.run(DFSOutputStream.java:546)
20/07/24 19:45:20 INFO db.DBInputFormat: Using read commited transaction isolation
20/07/24 19:45:20 INFO mapreduce.JobSubmitter: number of splits:1
20/07/24 19:45:20 INFO mapreduce.JobSubmitter: Submitting tokens for job: job_1595558750246_0001
20/07/24 19:45:20 INFO impl.YarnClientImpl: Submitted application application_1595558750246_0001
20/07/24 19:45:20 INFO mapreduce.Job: The url to track the job: http://hadoop01:8088/proxy/application_1595558750246_0001/
20/07/24 19:45:20 INFO mapreduce.Job: Running job: job_1595558750246_0001
20/07/24 19:45:35 INFO mapreduce.Job: Job job_1595558750246_0001 running in uber mode : false
20/07/24 19:45:35 INFO mapreduce.Job:  map 0% reduce 0%
20/07/24 19:45:48 INFO mapreduce.Job:  map 100% reduce 0%
20/07/24 19:45:49 INFO mapreduce.Job: Job job_1595558750246_0001 completed successfully
20/07/24 19:45:49 INFO mapreduce.Job: Counters: 30
        File System Counters
                FILE: Number of bytes read=0
                FILE: Number of bytes written=137395
                FILE: Number of read operations=0
                FILE: Number of large read operations=0
                FILE: Number of write operations=0
                HDFS: Number of bytes read=87
                HDFS: Number of bytes written=129
                HDFS: Number of read operations=4
                HDFS: Number of large read operations=0
                HDFS: Number of write operations=2
        Job Counters
                Launched map tasks=1
                Other local map tasks=1
                Total time spent by all maps in occupied slots (ms)=9426
                Total time spent by all reduces in occupied slots (ms)=0
                Total time spent by all map tasks (ms)=9426
                Total vcore-milliseconds taken by all map tasks=9426
                Total megabyte-milliseconds taken by all map tasks=9652224
        Map-Reduce Framework
                Map input records=6
                Map output records=6
                Input split bytes=87
                Spilled Records=0
                Failed Shuffles=0
                Merged Map outputs=0
                GC time elapsed (ms)=558
                CPU time spent (ms)=1570
                Physical memory (bytes) snapshot=175525888
                Virtual memory (bytes) snapshot=2091405312
                Total committed heap usage (bytes)=89653248
        File Input Format Counters
                Bytes Read=0
        File Output Format Counters
                Bytes Written=129
20/07/24 19:45:49 INFO mapreduce.ImportJobBase: Transferred 129 bytes in 32.0322 seconds (4.0272 bytes/sec)
20/07/24 19:45:49 INFO mapreduce.ImportJobBase: Retrieved 6 records.
[root@hadoop01 ~]#

可见sqoop将RDBMS（关系型数据库）中的数据导入HDFS的过程底层是通过MapReduce操作实现的。

导入结果如下：

查询导入

sqoop import \
--connect jdbc:mysql://192.168.88.110:3306/test \
--username root \
--password 123456 \
--target-dir /sqoop/mysql/student01 \
--delete-target-dir \
-m 1 \
--fields-terminated-by "\t" \
--query 'select name,age,address from student where 1=1 and $CONDITIONS;'

"'select name,age,address from student where 1=1 and $CONDITIONS;'"

结果如下：

导入指定列

sqoop import \
--connect jdbc:mysql://192.168.88.110:3306/test \
--username root \
--password 123456 \
--target-dir /sqoop/mysql/student02 \
--delete-target-dir \
--num-mappers 1 \
--fields-terminated-by "\t" \
--columns id,name \
--table student

结果：

使用sqoop关键字筛选查询导入数据

sqoop import \
--connect jdbc:mysql://192.168.88.110:3306/test \
--username root \
--password 123456 \
--target-dir /sqoop/mysql/student \
--delete-target-dir \
--num-mappers 1 \
--fields-terminated-by "\t" \
--table student \
--where "id=2"

结果：

mysql导入hdfs封装shell脚本

mysql-hdfs.sh

#!/bin/bash

read -p "请输入你的选择（1.导入全部  2.查询导入 3.基于列元素的导入 4.关键字筛选查询导入）：" choose


read -p "请输入数据库名：" database
read -p "请输入要查询的表名：" tableName

if [ $choose == 1 ]
then

sqoop import \
--connect jdbc:mysql://192.168.88.110:3306/$database  \
--username root \
--password 123456 \
--table $tableName \
--target-dir /sqoop/mysql/$tableName \
--delete-target-dir \
--m 1 \
--fields-terminated-by "\t"

elif [ $choose == 2 ]
then

read -p "请输入你要查询的sql语句(样例输入：'select name,sex from teacher where 1=1 and $CONDITIONS;'):" sql

sqoop import \
--connect jdbc:mysql://192.168.88.110:3306/$database \
--username root \
--password 123456 \
--target-dir /sqoop/mysql/$tableName \
--delete-target-dir \
-m 1 \
--fields-terminated-by "\t" \
--query $sql

elif [ $choose == 3 ]
then

read -p "请输入要查询的元素列（用逗号分隔）：" string

sqoop import \
--connect jdbc:mysql://192.168.88.110:3306/$database \
--username root \
--password 123456 \
--target-dir /sqoop/mysql/$tableName \
--delete-target-dir \
--num-mappers 1 \
--fields-terminated-by "\t" \
--columns $string \
--table $tableName

elif [ $choose == 4 ]
then

read -p "请输入要查询的关键字（例如："id=2"）：" string

sqoop import \
--connect jdbc:mysql://192.168.88.110:3306/$database \
--username root \
--password 123456 \
--target-dir /sqoop/mysql/$tableName \
--delete-target-dir \
--num-mappers 1 \
--fields-terminated-by "\t" \
--table $tableName \
--where  $string

else
echo "你输入的不对！！！"

fi

RDBMS(关系型数据库)到Hive

方法一：

sqoop import \
--connect jdbc:mysql://192.168.88.110:3306/test \
--username root \
--password 123456 \
--target-dir /sqoop/mysql/student \
--delete-target-dir \
--table student  \
--num-mappers 1 \
--hive-import   \
--hive-database db_user \
--fields-terminated-by "\t" \
--hive-overwrite \
--hive-table mysql_hive_student

==提示：该过程分为两步，第一步将数据导入到HDFS，第二步将导入到HDFS的数据迁移到Hive仓库==

==提示：第一步的保存目录是/sqoop/mysql/student==

结果：

方法二

将第一步和第二部分开执行，即将mysql中的数据导入hdfs中，再在hive中创建表，用load命令将数据从hdfs中导入hive表中。

第一步：（只导入id，name，age）用之前封装的shell

[root@hadoop01 ~]# mysql-hdfs.sh
请输入你的选择（1.导入全部  2.查询导入 3.基于列元素的导入 4.关键字筛选查询导入）：3
请输入数据库名：test
请输入要查询的表名：student
请输入要查询的元素列（用逗号分隔）：id,name,age

==第二步：在hive中创建表，然后导入数据至hive表中==

创建外部表：

hive (db_user)> create external table mysql_hive_student01(id int,name string,age int)
              > location '/external/mysql_hive_student01';
OK
Time taken: 0.118 seconds

导入数据

1	load data inpath '/sqoop/mysql/student/part-m-*' into table mysql_hive_student01

==有问题==
